MazeGenerator 🧩

Download on Modrinth

Build massive, themed mazes in Minecraft without freezing the server. The plugin generates the maze layout incrementally and places blocks over time with a configurable per-tick budget. Work is grouped per chunk, and chunks are only loaded on demand at the exact moment blocks need to be placed.

• Paper

Features ✨

• Streaming generation and placement - no giant in-memory queues.
• On-demand chunk loading only (never preloads).
• Autotuned per-tick time budget to protect TPS.
• Chunk-grouped placement (multiple cells per job) to reduce overhead.
• Weighted material themes for floor, wall, and top (themes.yml).
• Options for hollow walls and closed roofs.
• Tab-complete for arguments, plus /maze help, /maze stop, /maze reload.

---

Installation ⚙️

1. Build or download the plugin JAR.
2. Drop the JAR into your server’s plugins/ folder.
3. Start the server once to generate default config and data files.

Files created/used:

• plugins/MazeGenerator/config.yml - performance and behavior settings.
• plugins/MazeGenerator/themes.yml - material weights per theme.
• plugins/MazeGenerator/messages.yml - user-facing messages.

Use /maze reload after changing these files, or restart the plugin/server.

---

Commands ⌨️

• /maze - starts a build with sensible defaults near your position.
• /maze stop - stops all active maze builds.
• /maze help - prints usage and argument reference.
• /maze reload - reloads config.yml, themes.yml, and messages.yml.

Permissions:

• mazegenerator.maze - use /maze and view status.
• mazegenerator.reload - use /maze reload.

Arguments (key:value)

Order does not matter; tab-complete suggests keys and many values.

• x, y, z: World coordinates (defaults to your position).
• world: World name (defaults to your world).
• mazeSizeX, mazeSizeZ: Maze size in cells (odd enforced internally).
• cellSize: Block width and length of each cell footprint.
• wallHeight: Vertical wall height (excluding top layer).
• hasExits: true|false - ensure at least one exit at maze border.
• additionalExits: Extra exits on top of the first (0..N).
• hasRoom: true|false - carves a central rectangular room.
• roomSizeX, roomSizeZ: Room dimensions (cells) for the central room.
• erosion: 0..1 - occasional small holes in nearby walls while carving.
• closed: true|false - roof over paths as well (otherwise paths are open to sky).
• hollow: true|false - wall cells as a shell (edges only) for huge block savings.
• themeName: Theme key from themes.yml (tab-complete lists available themes).

Examples:

• /maze mazeSizeX:51 mazeSizeZ:51 cellSize:2 wallHeight:4 hasExits:true additionalExits:1 themeName:forest
• /maze world:world_nether x:100 y:80 z:-200 mazeSizeX:41 mazeSizeZ:41 themeName:snowy
• /maze mazeSizeX:75 mazeSizeZ:75 cellSize:3 wallHeight:5 hasExits:true hollow:true closed:false themeName:desert

---

Configuration (config.yml) 🛠️

Defaults are tuned to preserve TPS on most servers. Key settings:

• millis-per-tick (default 3) Base time budget per tick used by the builder. Autotune adjusts this up or down within bounds.

• jobs-batch-cells (default 64) How many maze cells the scheduler tries to collect per top-up. Larger values reduce overhead a little, but can increase burstiness.

• cells-per-job (default 16) How many cells to pack into a single placement job for a given chunk. Higher values reduce scheduler overhead and redundant chunk loads.

• set-block-data (default false) Attach CustomBlockData to placed blocks. For most builds this should remain false (saves I/O and memory).

• defer-wall-fill (default false) Build order option:

  • true: carve first (corridors appear quickly), then fill remaining walls; generally fewer total writes.
  • false: fill walls first, then carve; looks like a solid mass at first, then paths appear.

• autotune: (enabled by default)

  • min-millis-per-tick, max-millis-per-tick - bounds for the per-tick time budget.
  • increase-step, decrease-step - how fast the budget grows or shrinks.
  • spare-high, spare-low - thresholds based on remaining time in the current 50 ms tick.

• status-interval-jobs (default 1000) Prints a progress update in chat roughly every N jobs executed.

Note: The plugin loads chunks on demand at placement time. There is no preloading and no background chunk budgets.

Example: Smooth (minimal TPS impact)

millis-per-tick: 2
jobs-batch-cells: 32
cells-per-job: 8
set-block-data: false

autotune:
  enabled: true
  min-millis-per-tick: 1
  max-millis-per-tick: 4
  increase-step: 1
  decrease-step: 2
  spare-high: 18
  spare-low: 12

defer-wall-fill: true
status-interval-jobs: 500

Example: Balanced (default-like)

millis-per-tick: 3
jobs-batch-cells: 64
cells-per-job: 16
set-block-data: false

autotune:
  enabled: true
  min-millis-per-tick: 1
  max-millis-per-tick: 8
  increase-step: 1
  decrease-step: 2
  spare-high: 18
  spare-low: 12

defer-wall-fill: false
status-interval-jobs: 1000

Example: Fast (accept some risk of spikes)

millis-per-tick: 5
jobs-batch-cells: 128
cells-per-job: 32
set-block-data: false

autotune:
  enabled: true
  min-millis-per-tick: 2
  max-millis-per-tick: 10
  increase-step: 1
  decrease-step: 1
  spare-high: 20
  spare-low: 10

defer-wall-fill: true
status-interval-jobs: 750

---

Themes (themes.yml) 🎨

Themes control weighted material selection for three sections: floor, wall, and top.

Example:

desert:
  floor:
    SANDSTONE: 20
    RED_SANDSTONE: 10
  wall:
    SAND: 40
    CHISELED_SANDSTONE: 20
  top:
    SANDSTONE: 3

forest:
  floor:
    GRASS_BLOCK: 20
    DIRT: 2
  wall:
    OAK_LOG: 30
    OAK_LEAVES: 25
  top:
    OAK_LOG: 3

Weights are positive integers. Higher weight means more likely. If a section is empty, it falls back to STONE.

Tips:

• Use more variety in wall and top for a more organic look.
• Keep top materials lighter for interesting silhouettes.

---

Messages (messages.yml) 💬

• plugin-prefix, job-started, job-status, job-done, job-stopped, command-error, no-permission, config-reloaded.
• Color codes use & and are translated on send.

---

How Autotune Works (Quick) ⚖️

• Measures spare time within the current 50 ms server tick (based on a tick start event).
• If there is plenty of spare time (spare >= spare-high), it increases the per-tick time budget by increase-step up to max-millis-per-tick.
• If the tick is tight (spare < spare-low), it decreases by decrease-step down to min-millis-per-tick.
• The builder places blocks only until now + currentMillisPerTick in each tick.

---

Performance Tips 🚀

• Use hollow: true and a larger cellSize to reduce total blocks dramatically.
• Increase cells-per-job and jobs-batch-cells to reduce scheduling overhead.
• Keep set-block-data: false unless you really need it.
• Prefer defer-wall-fill: true for faster time-to-visible maze and fewer writes.

---

Troubleshooting 🧰

• "Maze seems stuck" or no progress:

  • Chat updates are periodic. Lower status-interval-jobs for more frequent feedback.
  • Check console for errors. If chunks are extremely far, each job will load them on demand; this can be slow but should not stall.

• TPS dips during build:

  • Lower millis-per-tick, jobs-batch-cells, or cells-per-job.
  • Keep autotune.enabled: true so the budget backs off automatically.

• Themes look too uniform:

  • Add more materials and weights to wall and top sections.

Have fun, cheers! 🎉
